DC Circuit Breaker YRL7-125DC
YRL7-125DC
YRL7-125 DC high segment capacity circuit breaker is specially designed for solar photovoltaic system, with current 63A-125A, voltage up to 1000VDC, segment capacity 6KA, in line with IEC/EN60947-2 standard.
Used in DC systems that need to be disconnected and protected when overcurrent or short circuit occurs, such as photovoltaic combiner boxes. The non-complementary design can be perfectly adapted to the charging and discharging system of the battery.
Used in DC systems that need to be disconnected and protected when overcurrent or short circuit occurs, such as photovoltaic combiner boxes. The non-complementary design can be perfectly adapted to the charging and discharging system of the battery.
Quantity
YRL7-125DC is mainly used in photovoltaic combiner box, energy storage and other DC systems that need to be disconnected and protected when overcurrent or short circuit occurs. Non-plarity design can fit battery charge and discharge system perfectly.
The DC Circuit Breaker YRL7-125DC is designed to provide reliable protection for DC systems up to 125 amps. The compact and rugged design makes it suitable for various applications, including solar power systems, telecom infrastructure, and marine electronics. Featuring a trip-free mechanism, it ensures safe and efficient operation in case of overload or short circuits. With its low power consumption and high interrupting capacity, this circuit breaker offers dependable performance and cost-effective protection. Whether you need to protect your equipment or comply with safety regulations, the YRL7-125DC is an ideal choice.
The DC Circuit Breaker YRL7-125DC is designed to provide reliable protection for DC systems up to 125 amps. The compact and rugged design makes it suitable for various applications, including solar power systems, telecom infrastructure, and marine electronics. Featuring a trip-free mechanism, it ensures safe and efficient operation in case of overload or short circuits. With its low power consumption and high interrupting capacity, this circuit breaker offers dependable performance and cost-effective protection. Whether you need to protect your equipment or comply with safety regulations, the YRL7-125DC is an ideal choice.
